Automatic Braided Sleeve Taping and Cutting Machine for OD 8–30 mm Tube WM-177

Name: Automatic Braided Sleeve Taping and Cutting Machine for OD 8–30 mm Tube WM-177
Brand: Wiromac
SKU: WM-177

HS Code 8461.50 Braided tube OD 8–30 mm 350–400 pcs/h (800 mm)

The WM-177 wraps non-elastic adhesive tape around braided tube at the programmed cut point, then cuts through the taped band — both new ends leave the machine bound, with no loose or frayed strands. It processes nylon and metal braided tube from OD 8 to 30 mm with tape 10–20 mm wide, the number of winding turns freely settable, and crawler feeding that grips the tube without crushing it. Cutting speed is 350–400 pieces per hour at 800 mm length with a smooth, burr-free cut face. The floor-standing unit measures 1700 × 600 × 1500 mm, weighs about 380 kg and runs on 220 V, 50 Hz, 1.8 kW with 0.6 MPa compressed air.

Specifications

Function	Tape wrapping at the cut point and cutting of braided tube in one cycle
Tube type	Nylon braided tube, metal braided tube
Winding diameter	OD 8 – 30 mm
Tape type	Non-elastic adhesive tape
Tape width	10 – 20 mm
Number of winding turns	Can be set
Feeding method	Crawler feeding
Cutter stroke	85 mm
Cutting speed	350 – 400 pieces/hour (length = 800 mm)
On-line cutting	Supported
Cutting effect	Smooth, no burr
Power	220 V, 50 Hz, 1.8 kW
Air pressure	0.6 MPa
Dimensions	1700 × 600 × 1500 mm (without protrusions)
Weight	About 380 kg
HS Code	8461.50 (common reference — final classification confirmed by your customs broker)
Certification	On request

Key features

Tape-then-cut sequence — the taping head binds the tube at the programmed position and the blade passes through the middle of the band, so both the cut piece and the remaining tube keep wrapped, fray-free ends
Works on metal braided tube as well as nylon — braids that cannot be melt-sealed still come off the machine with bound ends
Winding turns are a recipe setting and the holder takes standard non-elastic adhesive tape rolls 10–20 mm wide — no special consumables
Crawler feeding carries the tube between toothed belts instead of pinch rollers, holding feed length without crushing the braid, and on-line cutting lets the machine sit at the end of an existing line

What it processes

Nylon and metal braided sleeve cut to length with bound ends for wire harness over-braiding
Automotive, EV and appliance harness plants that kit pre-cut protective tube by the thousand
Cut-to-length tube pieces with taped ends for resale or assembly kitting

Suited for: nylon and metal braided tube from OD 8 to 30 mm that must arrive at assembly cut to length with bound, fray-free ends — taped at the cut point in the same machine cycle. Not suited for: plain corrugated conduit that needs no taping — the WM-177FY high-speed corrugated tube cutting machine cuts Φ4–32 mm loom far faster; flat braided sleeve and webbing that only need sealed ends belong on the WM-568 hot cutting machine, whose heated blade fuses material 1–100 mm wide; and taping along an already assembled harness — without cutting — is the job of the WM-467 wire harness taping machine for bundles Φ3–30 mm.

Engineering knowledge

Choose and troubleshoot this process

How to Choose a Tube and Pipe Cutting MachineChoose tube and pipe cutting equipment by material, diameter, wall thickness, rigidity, cut mechanism, tolerance, end quality and chip-control requirements.
Tube Cutting Defects: Causes and Corrective ActionsTroubleshoot angled cuts, crushed tube, burrs, stringing, length drift, corrugated-tube splitting errors and feed slippage.

Neither machine quite fits? New configurations reach our application engineers before they reach the catalog. Tell us your material and process; we will confirm what we manufacture and support, then recommend the right configuration. Get a tailored recommendation →

WM-177 — common questions

Why wrap tape before cutting instead of just cutting?

A plain cut through braided tube leaves free strand ends that unravel in handling. The WM-177 first wraps adhesive tape around the tube at the programmed position, then cuts through the center of that band — the tape stays on both sides of the cut, so the finished piece and the remaining tube are both bound. Unlike hot cutting, this also works on metal braid, which cannot be sealed by melting.

The sample photos show corrugated tube — can it run corrugated conduit too?

Yes — the taped-and-cut demo pieces in our gallery were produced on this machine from corrugated loom. The factory data lists nylon and metal braided tube as the primary tube types; if your material is different, send us a sample and we will run it and send you the result before you order. For plain corrugated conduit that needs no taping, a dedicated high-speed cutter is the faster, cheaper choice.

What tape does the machine use and how much does it apply?

Standard non-elastic adhesive tape, 10 to 20 mm wide, loaded on the roll holder. The number of winding turns is set on the controller per job, so you can trade tape consumption against how firmly the end needs to be bound.
