Automatic Hot Rope Cutting Machine with Heat-Sealed Ends, up to Φ20 mm WM-561

Name: Automatic Hot Rope Cutting Machine with Heat-Sealed Ends, up to Φ20 mm WM-561
Brand: Wiromac
SKU: WM-561

CE Certified HS Code 8479.89 Rope up to Φ20 mm 60–210 pcs/min

The WM-561 cuts nylon rope, cord and webbing with a heated blade that reaches 460 °C, fusing both cut faces at the moment of the cut so braided synthetic ends come off sealed — no fraying and no separate tipping step. It accepts rope up to Φ20 mm including double-layer sheath-and-core constructions, cuts programmed lengths from 0.1 to 99,999.9 mm at ±0.1 mm accuracy, and delivers 60–210 pieces per minute depending on length. Belt feeding moves the rope without crushing the braid. The bench unit measures 650 × 480 × 420 mm, weighs 66 kg net and runs on AC220 V at 560 W.

Specifications

Function	Hot cutting of rope, cord and webbing with heat-sealed ends
Rope cutting diameter	Max. Φ20 mm
Cutting length	0.1 – 99,999.9 mm
Cutting accuracy	±0.1 mm
Cutting speed	60 – 210 pcs/min (depending on cutting length)
Maximum temperature	460 °C
Power	AC220 V, 560 W
Dimensions	650 × 480 × 420 mm (L × W × H)
Gross weight	87 kg
Net weight	66 kg
HS Code	8479.89 (common reference — final classification confirmed by your customs broker)
Certification	CE (certificate provided with shipment)

Key features

The hot blade seals as it cuts — braided nylon and polyester ends leave the machine fused, with no fraying and no second tipping operation
Takes double-layer sheath-and-core rope up to Φ20 mm — the construction used in climbing, marine and safety lines
60–210 pieces per minute with ±0.1 mm repeatability turns rope cutting from a scissors job into a production process
Blade temperature is settable up to 460 °C to match the material, from polypropylene webbing to dense nylon braid

What it processes

Nylon and polyester rope cut-to-length with sealed ends for safety, marine and outdoor products
Webbing, cord and drawstring cutting for bags, apparel and sporting goods
Paracord, elastic cord and braided-sleeve production runs

Suited for: synthetic rope, cord and webbing up to Φ20 mm — nylon, polyester, polypropylene, including double-layer sheath-and-core rope — wherever cut ends must ship sealed and fray-free. Not suited for: wire and cable work — for conductor cutting, pick from the wire cutting and stripping machines — nor steel wire rope or natural fibers that cannot heat-seal; for those, custom sourcing is the route: tell us your spec — sourcing unusual machines is what we do.

Rope constructions vary more than specifications suggest, so we prove the cut on your material: send 2–3 meters of your actual rope or webbing and we cut it on this machine on video — sealed ends on camera — before you commit.

Engineering knowledge

Choose and troubleshoot this process

How to Choose a Tube and Pipe Cutting MachineChoose tube and pipe cutting equipment by material, diameter, wall thickness, rigidity, cut mechanism, tolerance, end quality and chip-control requirements.
Tube Cutting Defects: Causes and Corrective ActionsTroubleshoot angled cuts, crushed tube, burrs, stringing, length drift, corrugated-tube splitting errors and feed slippage.

Neither machine quite fits? New configurations reach our application engineers before they reach the catalog. Tell us your material and process; we will confirm what we manufacture and support, then recommend the right configuration. Get a tailored recommendation →

WM-561 — common questions

Do the cut ends really not fray?

The blade runs at up to 460 °C, so synthetic fibers melt and fuse across the full cross-section at the moment of the cut — both the cut piece and the remaining rope end come away sealed. Natural fibers such as cotton do not fuse; the machine is intended for synthetics like nylon, polyester and polypropylene.

How fast is it in practice?

60 to 210 pieces per minute depending on cut length — short pieces run near the top of the range, long pieces are limited by feed time. Length is programmed from 0.1 to 99,999.9 mm with ±0.1 mm accuracy, so a batch changeover is a parameter change, not a mechanical adjustment.

What is the WM-561 not meant to cut?

Wire and cable — a hot blade is the wrong tool for copper conductors, and insulation stripping is a different process; see the wire cutting and stripping machines category for those. Steel wire rope and natural-fiber rope that cannot heat-seal are also outside its range.
